Control Systems

Multi-Axis Control and Data Acquisition Systems


Don’t have the time or budget for a fully custom-built test system? Consider one of Genuen’s turnkey solutions for multi-loop control and data acquisition. We offer powerful, flexible solutions ranging from low-cost desktop test cell controllers to pre-configured rack systems, all standardized on the same technology platform.

Test Cell Controllers for Your Industry

Automotive

Automotive

Aerospace

Aerospace

Test Planning

Medical Devices

noun_component_3120643

Components



Choose the Right Test Cell Controller for Your Application:





RAPID II

LEARN MORE

DynEDGE

Learn More

ServoEDGE

LEARN MORE

 Features







 Out-of-the-box functionality

 Deterministic performance

 Easy connectivity

 Open source technology

 High power output



 Highly customizable



 Applications







 Dynamometer



 Servo hydraulic



 Driveline test cell



 Software







Microsoft Windows operating system

 NI VeriStand test software

Genuen INERTIA add-on

Closed Loop Control







 4-axis control

 High speed control up to 1 kHz

 Configurable output drive

± 10 V or 4-20 mA

or ± 100 mA

± 10 V or 4-20 mA

± 10 V or 4-20 mA

or ± 100 mA

 Multiple gain parameters

Data Acquisition I/O







 Voltage input

8 SE or Diff

± 10 V or 4-20 mA,

incl. 24 V bias

30 SE or 14 Diff

± 10 V or 4-20 mA

8 SE or 8 Diff

± 10 V or 4-20 mA

 Voltage output

see Closed Loop Control above

see Closed Loop Control above

see Closed Loop Control above

 Thermocouple

8

32

4

 Strain



8

8

 Frequency

up to 12 (5-24 V)

2 (50 mV to 250 V)



 Encoder

up to 4

2



 LVDT





4

 Digital input

16 (24 V)

29 (24 V), 4 (TTL)

29 (24 V), 4 (TTL)

 Digital output

16 (24 V)

4 (TTL)

4 (TTL)

 Relay



31

31

 Expansion I/O

External

In-rack

In-rack

 Physical







 Enclosure

19" 5U rack-mount

Full-height 19" rack

Full-height 19" rack

 Industrial temperature ratings





All controllers include:

  • Operator PC preloaded with software

  • Digital user manual and online video tutorials

  • 1-year customer support via phone and email



3D Connecting Sensor to Data Aquisiton
WHITE PAPER

Connecting Sensors to Data Acquisition Systems Analog Inputs


This white paper discusses the recommended methods for connecting sensors and/or external signals to +/-10V analog inputs that are provided on data acquisition systems for end user connection. It includes system diagrams and photos of the most common cables.

DOWNLOAD WHITE PAPER

rapid

Rapid II

Rapid II combines the latest in digital control technology with off-the-shelf hardware to produce powerful, flexible test cell control at a cost-effective price.

Learn More

noun_control_3519862

ServoEDGE

ServoEDGE is an integrated, multi-loop test cell control and data acquisition system designed specifically for hydraulic and servo-hydraulic applications.

Learn More

noun_Controller_3671811

DynEDGE

The DynEDGE dyno controller is an integrated, multi-loop test cell control and data acquisition system for dynamometer applications.

Learn More

Get Started with Your Test Cell Control System


Learn more about our products or request a consultation with an experienced engineer.
